DTHT-K80

Sidewall Sprinkler-Quick Response-K80 (5.6)-1/2"

Standard and Quick Type Sprinkler

Pendent sprinklers are specifically designed for projects classified under low and medium hazard categories. Parameters such as the K factor, response, and temperature are determined during the design process according to the project's requirements. Quick response sprinklers should never be used in high hazard class locations. Upon installation, the deflector portion of the sprinkler is positioned downward, and when activated, it intervenes in fires with a conical water flow. These sprinklers are preferred in various application areas such as residential buildings, hospitals, hotels, shopping centers, and dormitories.

Product Features

Approvals

UL, FM, TSE

K Factor

K5,6 (80)

Thread Size

1/2" NPT

Response

Quick Response

Temperature

57°C, 68°C, 79°C, 93°C, 141°C

Surface

White, Chrome, Brass

Documents

Related products

Upright-Standard Response-K80 (5.6)-1/2"

Upright sprinkler is specifically designed for projects classified under low and medium hazard categories. Parameters such as the K factor, response, and temperature are determined project-specifically through design and calculations. Upon installation, the deflector part of the sprinkler is positioned in an upward direction, and when activated, it intervenes in fires with a downward conical water flow. These sprinklers are preferred in various usage areas such as parking lots, workshops, waste collection centers, and shopping malls.

Pendent-Standard Reaction-K80 (5.6)-1/2"

Pendent sprinklers are specifically designed for projects classified under low and medium hazard categories. Parameters such as the K factor, response, and temperature are determined during the design process according to the project's requirements. Upon installation, the deflector portion of the sprinkler is positioned downward, and when activated, it intervenes in fires with a conical water flow. These sprinklers are preferred in various application areas such as residential buildings, hospitals, hotels, shopping centers, and dormitories.

Sidewall Sprinkler-Standard Response-K80 (5.6)-1/2"

Sidewall sprinkler is specifically designed for use in projects aimed at low hazard classifications. Parameters such as the K factor, response, and temperature are determined along with the project type, design, and calculations. Upon installation onto the piping network, the deflector part of the sprinkler is mounted parallel to the wall, and when activated, initiates a downward and forward conical water flow. These sprinklers are preferred in various usage areas such as residential buildings, hospitals, hotels, shopping centers, and dormitories.

Upright-Quick Response-K80 (5.6)-1/2"

Upright sprinkler is specially designed for projects classified under low and medium hazard categories. Parameters such as the K factor, response, and temperature are determined project-specifically through design and calculations. Quick response sprinklers should never be used in high hazard class locations. Upon installation, the deflector part of the sprinkler is positioned upward, and when activated, it intervenes in fires with a downward conical water flow. These sprinklers are preferred in various usage areas such as parking lots, workshops, waste collection centers, and shopping malls.
